Forged Steel Backup Rolls
The grades have 3% and 5% Chromium together with Molybdenum and Vanadium, differentially hardened to achieve bainitic to martensitic shell with spheriodized pearlitic core. CSMETAL ISTANBUL produces forged steel back up rolls for hot and cold strip mills. These rolls are used in continuous, Semi Continuous and Steckel Hot Strip Mills, also Tandem Cold Strip Mill and Temper Mills. |
 |
|
SB H 62F- Tempered Martensite(x200) |
|
||||||||||||||||||
|
Roll Grade |
Barrels Hardness (ShC) |
C (%) |
Si (%) |
Mn (%) |
Cr (%) |
Mo (%) |
V (%) |
|
SB H 62 F |
62 |
0.52-0.62 |
0.2-0.5 |
0.3-0.7 |
3.0-3.3 |
0.3-0.6 |
0.1-0.3 |
|
SB H 64 F |
64 |
0.52-0.62 |
0.2-0.5 |
0.3-0.7 |
3.0-3.3 |
0.3-0.6 |
0.1-0.3 |
|
SB Mo H 64 F |
64 |
0.55-0.65 |
0.2-0.5 |
0.3-0.7 |
3.0-3.3 |
0.6-1.0 |
0.1-0.3 |
|
SB Mo H 66 F |
66 |
0.55-0.65 |
0.2-0.5 |
0.3-0.7 |
3.0-3.3 |
0.6-1.0 |
0.1-0.3 |
|
SB Cr H 66 F |
66 |
0.45-0.55 |
0.2-0.5 |
0.3-0.7 |
5.0-5.3 |
0.3-0.6 |
0.1-0.3 |
|
SB Cr H 68 F |
68 |
0.45-0.55 |
0.2-0.5 |
0.3-0.7 |
5.0-5.3 |
0.3-0.6 |
0.1-0.3 |
|
SB Cr Mo H 70 F |
70 |
0.5-0.6 |
0.2-0.5 |
0.3-0.7 |
5.0-5.3 |
0.6-1.0 |
0.1-0.3 |
|
SB Cr Mo H 72 F |
72 |
0.5-0.6 |
0.2-0.5 |
0.3-0.7 |
5.0-5.3 |
0.6-1.0 |
0.1-0.3 |
Note: On request, other roll grades not specified in the table can be produced.
