Clear Chill Rolls
Clear chill iron rolls are cast to produce an outer shell layer free of graphite, containing substantial amounts of carbides. Rolls of this family have excellent wear resistance but are sensitive to fire cracking. These rolls are either produced single or double poured depending on the application. |
 |
 |
 |
|
CCNiH72C- Acicular Matrix with Carbides (x400) |
CC64C-Pearlitic Matrix with Carbides (x400) |
|
Roll Grade |
Barrels Hardness (ShC) |
C (%) |
Si (%) |
Mn (%) |
Cr (%) |
Ni (%) |
Mo (%) |
Composition hardness and Properties of core material |
|
CC 60 C |
60 |
3.0-3.6 |
0.3-0.7 |
0.1-0.5 |
0.3-1.4 |
0.2-0.8 |
0.0-.0.3 |
See core Material Info in link1 |
|
CC 64 C |
64 |
3.0-3.6 |
0.3-0.7 |
0.1-0.5 |
0.3-1.4 |
0.2-0.8 |
0.0-.0.3 |
See core Material Info in link1 |
|
CC 68 C |
68 |
3.0-3.8 |
0.3-0.7 |
0.1-0.5 |
0.3-1.4 |
0.4-1.0 |
0.0-.0.3 |
See core Material Info in link1 |
|
CC Ni H 72 C |
72 |
3.2-3.8 |
0.3-0.7 |
0.1-0.5 |
0.8-1.5 |
1.5-2.5 |
0.2-0.6 |
See core Material Info in link1 |
|
CC Ni H 76 C |
76 |
3.2-3.8 |
0.3-0.7 |
0.3-0.8 |
0.8-1.5 |
2.0-3.5 |
0.2-0.6 |
See core Material Info in link1 |
|
CC Ni H 80 C |
80 |
3.2-3.8 |
0.3-0.7 |
0.3-0.8 |
0.8-1.5 |
2.0-3.5 |
0.2-0.6 |
See core Material Info in link1 |
Note: On request, other roll grades not specified in the table can be produced. Cores for compound rolls can be produced with Grey, Compact or Nodular cast iron.
